1. Layer cage is used to raise laying chickens, keep birds from 12 weeks to adult

2. Automatic layer cage system include automatic cage, automatic drinking system, automatic feeding system, automatic manure cleaning system, automatic egg collection system

3. The automatic system very suitable for big farm like from 10,000 to 50,000 birds

4. Automatic chicken battery layer cages are a kind of poultry farming system for the laying chicken. Which is primarily for create a comfortable living environment for hens and achieving maximum egg production efficiently. The multiple tiers design of battery layer cages enables customers to achieve higher stocking density of layers, so that can gain greater profits

5. According to market feedback, the price of eggs has been increasing, which is a good opportunity for chicken farmers, eggs and meat are indispensable parts of people's lives, and the market will become larger and larger in the future. It is very necessary to choose a complete set of high-quality cage equipment. Sometimes the cost of the equipment can be paid back within 1 year and the equipment can be used for more than 20 years. That's a huge potential profit

Specifications

1. A type 3 tier 120 capacity automatic layer cage

   Cage size: 2.2m*2.4m*1.65m(L*W*H)

   Capacity: 120 birds each set

   Total nests(doors): 30nests(doors) per cage

   Main part: automatic layer cage, automatic drinking system, automatic feeding system, automatic egg collection system, automatic manure cleaning system

2. A type 4 tier 160 capacity automatic layer cage

   Cage size: 2.2m*2.4m*1.95m(L*W*H)

   Capacity: 160 birds each set

   Total nests(doors): 40 nests(doors) per cage

   Main part: automatic layer cage, automatic drinking system, automatic feeding system, automatic egg collection system, automatic manure cleaning system

We are always happy to support our customers and partners with technical questions, products you may want to learn more, click the name to visit
1. Automatic battery cage for pullet, brooder, layer, chicken parents and broiler
2. Chicken feed mill, manure drying machine and egg collection
3. Deep litter plasson drinker, feeder and broiler slaughtering equipment
4. Other poultry farm equipment...
Bookmark our website and contact us now to making enquiry, visiting to our office and factory and checking the sample...

Office and factory address in Nigeria

1. Lagos factory address: Rose of sharon plaza by oko filling bus stop, igando road, opposite oando filling station, Lagos, Nigeria

2. Lagos new warehouse address: No 110/120 ikotun-idimu road, alake bus-stop, Lagos, Nigeria

3. Our Lagos factory can produce layer cold galvanized cages, 96 birds and 128 birds capacity

4. All of the material, production machine, are imported from China

5. We are the manufacturer of chicken cage and poultry equipment. You could get one stop services,we provide you with complete raising solutions, we also have other layer cage, broiler cage, brooder cage, A type automatic cage system H type automatic cage system, manure removal machine, manure dryer machine, feed mixer and grinder machine, automatic bell drinker, feed pellet machine, manual drinker, manual feeder, trolley feeding machine and so on

Details and advantage of part of cages

Cage mesh

1. Material: Q235 wire, big tensile strength and yield strength

2. Surface treatment: 275/m2 hot dip galvanized cage with over 20 years lifespan

3. Advantage: reasonable size to ensure suitable space for each birds, increasing egg laying rate, prevent the birds peck manure and scurry

Cage frame

1. Material: hot dip galvanized steel, no easy to rust

2. Strong and stable

3. Advantage: reasonable stagger distance between upper and low cage, prevent the manure from upper cage drop to lower birds

Feeding system

1. Feed trough: PVC material, best quality, can bear the weight of 3 people

2. Feed hopper: each tier with two hoppers, thickness is 1.2mm, hot dip galvanized

3. Advantage: easy to clean, hot dip galvanized material with long service, up to 20 years, control the output amount to reduce the waste of feed

Drinking system

1. Water pipe: PVC material

2. Nipple drinker: Stainless steel material, not easy to rust, no leakage, keep cage dry and clean

3. Water pressure regulator: adjust water pressure

4. Advantage: generally, farm chicken houses with fully automatic equipment are very long. The water pressure regulator can control the flow of water to the end of the water pipe to ensure that all chickens can drink water

Silo for keep feed

1. Material is hot dip galvanized steel, zinc thickness is 275g/m2

2. Capacity: 5 tons, 8 tons, 10 tons, 15 tons, 20 tons, it can be suggested according to your chicken capacity, in general a chicken eat 0.2-0.25kg per day

3. Advantage: reduce the cost of artificial feeding feed, improve feeding efficiency, realize automatic integrated management, quantitative feeding, it is beneficial to breeding health and reduce feed waste, reducing breeding costs

Egg collection system

1. Material: hot dip galvanized

2. Egg conveying belt: highly smooth, dry, and durable to protect chicken eggs

3. Clips for eggs collecting belt are included

4. Advantage: broken egg rate is less than 0.08%

Manure cleaning system

1. Conveying belt: PP material, more than 10 years service time

2. Conveying speed: 3m per minute

3. Advantage: reduce your labor costs, simple and convenient operation, clean up manure very cleanly, keep the chicken house dry and clean, reduce bad smell, ensure chicken health and reduce disease rate

Why choose fully automatic laying cage system

1. Save land

2. Simple and reliable technical design. The A type cage frame is more stable, and the chicken manure will fall directly to the ground for easy cleaning

3. Unique structure,saving time and effort

4. Mature galvanizing process, long service life, suitable for humid and high temperature countries.

5. Reduce labor, such as Fully automatic system, 50,000 chickens only need 2 workers to complete various tasks

6. A stable and controllable living environment, the egg production rate exceeds 96%, an increase of 10%

7. Stable and controllable living environment and well designed egg collector, egg damage rate is less than 0.08%

8. One investment, 20 years of use quality, Bring you huge profits

Our best service

1. We are the professional battery poultry cage system and equipment manufacturer in Nigeria

2. We can provide professional poultry farm solutions and services

3. We have warehouse and factory in Lagos, you can check our goods at any time before you pay

4. We can provide poultry farm and chicken house floor plan design according to your land size

5. In our Lagos office, we have 4 professional installation teams, we can provide you installation guidance, and can also test the machine for you

6. We work with local driver, can delivery the goods from our warehouse to your farm location. The whole transportation is guaranteed, you can contact the driver at any time to confirm your goods

7. We have USD account, Naira account, RMB account, Pound account, Euro account, it depends on your convenient way
